Specification

型號 Item No.  HL-FL-T8H600-E UM

Module Spec.

Items  Description
Dimension  Ø26.8 ± 0.2mm x L577 mm ± 1mm
Weight  150 g ± 15 g
Housing/ Color  Al Alloy
Cover  PC
Tip  PC

Electric Spec.

Input Voltage  ACV 90~240V
Driver Current  Electrically Stabilized LED Actuator
Input Frequency  50-60Hz
Electrostatic Discharge  ±4.0 KV(HBM)
Power Consumption  10 W ± 1 W
Average Life span  ＞40,000 Hr

Optical Spec.

Light SMD 5630 / 48 pcs
Color True White / Warm White
Luminous Efficiency  ＞83.19 lm/W (TW)、72.73 lm/W (WW)
Color Temperature  TW 5350 - 6500K / WW 2700 - 3500K
Operating Temperature Range  - 30 ~ 65℃
Luminous flux(lm)  TW 831 lm / WW 727 lm
CRI  5630＞80%
Rated Lumen  ≦15% (20,000 hours)

Others

Certification  Driver CE
Packaging  1 dozens / Carton
User's Manual  LH-FL-T8H600-E UM

2800K VS 6000K

3200K VS 6000K
